How to Programme
5.6 Parameters: 8-** Communications and
Options
5.6.1 8-0* General Settings
8-01 Control Site
Option:
[0] Digital and ctrl. word Control by using both digital input
*
[1] Digital only
[2] Control word only
5 5
The setting in this parameter overrides the settings in par.
8-50 to 8-56.
8-02 Control Word Source
Option:
[0]
[1]
*
[2]
8-03 Control Word Timeout Time
Range:
1.0 s [0.1 -
*
18000.0 s]
This parameter specifies which action should be performed,
if a timeout of the control word occurs.
8-04 Control Word Timeout Function
Option:
[0]
*
[2]
[5]
8-06 Reset Control Word Timeout
Option:
[0]
*
[1]
42
Function:
and control word.
Control by using digital inputs only.
Control by using control word only.
Function:
None
FC RS485
FC USB
Function:
Enter the maximum time expected to pass
between the reception of two consecutive
telegrams. If this time is exceeded, it
indicates that the serial communication has
stopped. The function selected in
8-04 Control Word Timeout Function will then
be carried out. The time-out counter is
triggered by a valid control word.
Function:
Off
Stop
Stop and trip
Function:
Do not reset
Do reset
MG.33.X2.02 - VLT
®
VLT Active Front End AFE 302 Operating Instructions Liebherr
5.6.2 8-1* Control Word Settings
Parameters for configuring the option control word profile.
This parameter selects the interpretation of the control word
and status word. Valid selections are determined by installed
option.
8-10 Control Word Settings
Option:
[0]
*
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
®
is a registered Danfoss trademark
FC AFE profile
Bus Control Word
AFE Profile
Bit = 0 Bit = 1
- -
- -
- -
- -
- -
- -
Stop Start
No Function Reset
- -
- -
Data not valid Data valid
- -
- -
- -
- -
- -
Function:
