4.1.12 13-** Smart Logic

Param- Parameter description
eter #
13-0* SLC Settings
13-00 SL Controller Mode
13-01 Start Event
13-02 Stop Event
13-03 Reset SLC
13-1* Comparators
13-10 Comparator Operand
13-11 Comparator Operator
13-12 Comparator Value
13-1* RS Flip Flops
13-15 RS-FF Operand S
13-16 RS-FF Operand R
13-2* Timers
13-20 SL Controller Timer
13-4* Logic Rules
13-40 Logic Rule Boolean 1
13-41 Logic Rule Operator 1
13-42 Logic Rule Boolean 2
13-43 Logic Rule Operator 2
13-44 Logic Rule Boolean 3
13-5* States
13-51 SL Controller Event
13-52 SL Controller Action
13-9* User Defined Alerts
13-90 Alert Trigger
13-91 Alert Action
13-92 Alert Text
13-9* User Defined Readouts
13-97 Alert Alarm Word
13-98 Alert Warning Word
13-99 Alert Status Word
MG20OB02
Programming Guide
Default value 4 set-up
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[0] Do not reset
SLC All set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 1 set-up
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[0] False 2 set-ups
[0] Info 2 set-ups
ExpressionLimit 2 set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Danfoss A/S © 05/2018 All rights reserved.
Change during Conversion
operation index
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -3
TRUE -
TRUE -
TRUE -3
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE 0
FALSE 0
FALSE 0
FALSE 0
Type
Uint8
Uint8
Uint8
4 4
Uint8
Uint8
Uint8
Int32
Uint8
Uint8
TimD
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
VisStr[20]
Uint32
Uint32
Uint32
263
