Alarm Window
Abort Window

7.5.2 Zone Edit Fields

Zone Name
Group Name
Zone Locked/Unlocked
Display/Hide Zone

7.5.3 Setpoint Limits

Temperature Minimum
Temperature Maximum
Power Minimum
Power Maximum
Zone Edit Fields
v 1.1 — July 2015
Item
Touch this field to display a keypad for adjusting the upper and lower
alarm limits.
Touch this field to display a keypad for adjusting the upper and lower
abort limits.
Item
Touch this field to display a keyboard for assigning a custom name to a
zone or group of zones.
Touch this field to define a name for a group of selected zones. All zones
assigned a group name are used to create group views in the Multi Group
View as well as create a Shortcut Icon button in the Shortcut section on
the Home screen.
Touch this field to display a dialog to lock or unlock zone(s). If a zone(s) is
locked, it will prevent any changes from being made to it from the Quick
Set screen.
Touch this field to display a dialog to display or hide a zone(s). If hide is
selected, the zone(s) will be removed from all the Zone Data View
screens.
Item
The minimum and maximum values limit what temperature the
temperature setpoint can be changed to.
The minimum and maximum values limit what temperature the power
setpoint can be changed to.
Making Adjustments
Description
Description
Description
67
