User Guide
Chapter 16 UltraSync-E, If Equipped
This chapter describes the screens, controls and troubleshooting specific to UltraSync-E
(Electric) systems. These screens and controls are not available when the controller is used
with any other hot runner system.
IMPORTANT!
Controllers for UltraSync-E hot runners are designed for use with a specific hot runner.
Contact the nearest Husky Regional Service and Sales office before attempting to use the
controller with any other hot runner.
16.1 Connecting the Controller
To connect the controller to the injection molding machine, do the following:
IMPORTANT!
Only qualified personnel should be permitted to make modifications to the machine
interface.
1.
CAUTION!
Electrical hazard – risk of damage to the controller. All signals sent to the controller
must be from dry or potential-free contacts.
2.
Connecting the Controller
Connect the supplied X-100 interface cable to the X-100 connector on the controller.
Refer to
Section 16.6
for more information about signals.
Using the electrical schematics for the controller and the machine, connect the X-100
cable to the machine. Some modifications to the machine may be required to connect
the cables to the appropriate signal source or destination. Contact the nearest Husky
Regional Service and Sales office for assistance.
v 1.1 — July 2015
UltraSync-E, If Equipped
189
