7.5.1 Frequently Used Fields

Temperature Setpoint
Power Setpoint
Zone On/Off
Regulation Mode
Alarm Window
Abort Window

7.5.2 Zone Edit Fields

Zone Name
Group Name
Zone Locked/Unlocked
Display/Hide Zone
Frequently Used Fields
v 2.3 — September 2015
Item
Touch this field to display a keypad for adjusting a zone(s) setpoint in
Auto or Monitor regulation.
Touch this field to display a keypad for adjusting the percentage of
power output when a zone(s) is in Manual regulation.
Touch this field to turn the selected zone ON or OFF. A dialog appears and
allows the user to choose a value. The default is ON.
This setting allows users to set the regulation mode for the selected zone.
AUTO or Automatic (closed loop) means the system will use a
thermocouple to control the temperature. MAN or Manual (open loop)
means the system will only apply power (0 to 100%) to the heater and not
look for thermocouple feedback. MON or Monitor means the system will
only monitor the temperature of a thermocouple (no power output).
Touch this field to display a keypad for adjusting the upper and lower
alarm limits.
Touch this field to display a keypad for adjusting the upper and lower
abort limits.
Item
Touch this field to display a keyboard for assigning a custom name to a
zone or group of zones.
Touch this field to define a name for a group of selected zones. All zones
assigned a group name are used to create group views in the Multi Group
View as well as create a Shortcut Icon button in the Shortcut section on
the Home screen.
Touch this field to display a dialog to lock or unlock zone(s). If a zone(s) is
locked, it will prevent any changes from being made to it from the Quick
Set screen.
Touch this field to display a dialog to display or hide a zone(s). If hide is
selected, the zone(s) will be removed from all the Zone Data View
screens.
Making Adjustments
Description
Description
