4.1.3.4 Alarm Buttons

4.1.3.5 System and User Management Buttons

4.1.4 Dialog Box Buttons

The following buttons are available in Altanium dialog boxes.
Alarm Buttons
v 1.1 — July 2015
Touch the Silence Horn button to silence the audible alarm.
Touch the Alarm Status button to access the Alarm screen. The time and a
description of the highest priority active alarm will be displayed. If an alarm
is active, the Triangle Icon (Warning) will turn yellow and the background
of the button will flash red.
Displays the name of the current user logged in. Touch the User Log
off/Log on button to display the User Login dialog box. This button
toggles between Login and Logout
Touch the Help button to launch the PDF viewer and display the User
Guide on the screen.
Touch the Print button to open the Print dialog box containing the
available printing choices.
The Mold Setup Info button displays the currently loaded mold and
associated mold folder. The upper word is the name of the mold folder. The
lower word is the name of the mold setup file. Touch this area to display the
Mold Setup screen.
Touch the Language Selection button to display and select the available
screen languages.
