Zone Selection In The Text View Screen; Sorting - Husky Altanium Matrix2 User Manual

User Guide
Table 7-2
Select All
Clear All
Figure 7-6 Text View Screen - Full Screen Mode

7.4.1 Zone Selection in the Text View Screen

Use the Text View screen to select one or multiple zones.
•
•

7.4.2 Sorting

Information can be sorted on the Text View screen by selecting the header field of each
column. Sorting can be in ascending or descending order. A red line denotes the current
sorting.
Information can be sorted according to the dynamic columns (for example, current (Amps),
voltage (VAC), etc.). This can be helpful when trying to figure out which zone is drawing the
most current at any moment. The ability to select column headings in order to sort
information is used throughout Altanium.
Zone Selection in the Text View Screen
Text View Screen Button Descriptions (Continued)
Button
Touch this button to select all zones in the system. This will navigate to
the Quick Set screen
Touch this button to clear all zone selections
To view one zone, touch the desired zone text.
To view multiple zones, touch and hold the first zone for one second, and then touch the
last zone.
v 1.1 — July 2015 Making Adjustments
Description
65
