User Guide

7.5.16.3 Changing the Manual Boost Setpoints and Limits

It may be necessary to raise the temperatures in the mold for a period of time. This can be
done on the system header by selecting the Manual Boost button (or Remote Boost from a
remote location as an option) without needing to change the normal setpoint. Specify the
temperatures to heat the heaters in the mold to when the system is in Boost. The default
setting is no chg (no change) which means nothing will happen when Boost is activated.
To change a boost setpoint and boost setpoint limits for a zone, do the following:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. Touch the Power Minimum field and enter a value.
11. Touch the Accept button.
12. Touch the Power Maximum field and enter a setpoint value.
13. Touch the Accept button.

7.5.16.4 Changing the Remote Boost Setpoints and Limits

To change a remote boost setpoint and remote boost setpoint limits for a zone, do the
following:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. Touch the Power Minimum field and enter a value.
11. Touch the Accept button.
12. Touch the Power Maximum field and enter a setpoint value.
13. Touch the Accept button.
Changing the Manual Boost Setpoints and Limits
Touch the zone to be changed.
Touch the Temperature Setpoint field and enter a value.
Touch the Accept button.
Touch the Temperature Minimum field and enter a value.
Touch the Accept button.
Touch the Temperature Maximum field and enter a value.
Touch the Accept button.
Touch the Power Setpoint field and enter a value.
Touch the Accept button.
Touch the zone to be changed.
Touch the Temperature Setpoint field and enter a value.
Touch the Accept button.
Touch the Temperature Minimum field and enter a value.
Touch the Accept button.
Touch the Temperature Maximum field and enter a value.
Touch the Accept button.
Touch the Power Setpoint field and enter a value.
Touch the Accept button.
v 1.1 — July 2015
Making Adjustments
77
