Husky Altanium Matrix2 User Manual page 93

User Guide
Figure 7-9 ART Process Screen
Table 7-3
Status Text
Zone Selection Grid
Table 7-4
Start ART Process
Cancel ART Process
Reset ART Process
Edit ART Values
ART Process Screen
v 1.1 — July 2015
ART Process Screen Item Descriptions
Item
The current ART status.
The selection grid indicates the status of each zone.
Yellow represents a zone that is selected.
A yellow caution triangle marks a zone that cannot be ARTed (for
example, a zone set to manual regulation mode or a zone with errors).
An hourglass indicates ART is in progress.
A green check mark represents a zone that has already been ARTed.
A question mark represents a zone that is not ARTed.
ART Process Screen Button Descriptions
Button
Touch the Start ART Process button to start the ART process.
Touch the Cancel ART Process button to stop the ART process.
Touch the Reset ART Process button to reset the ART parameters for the
selected zones. The next time the system is started, it will perform the
ART process on those zones again.
Touch the Edit ART Values button to open the Edit Art Values dialog
box and view/change the ART parameters. ART values can be changed
one zone at a time, while the controller is running.
Making Adjustments
Description
Description
81
