Peak Open Force
Peak Close Force

16.4 UltraSync-E Setup Screen

Configure the UltraSync-E advanced options on the UltraSync-E Setup screen. UltraSync-E
can only be configured when the user level is sufficient and UltraSync-E is not engaged.
Figure 16-3 UltraSync-E Setup Screen

16.4.1 Monitoring

Monitoring
At-Position Window The position window within which the valve stems
are reported "At Open Position" or "At Close
Position".
UltraSync-E Setup Screen
v 1.1 — July 2015
Item
Peak force during the last open motion.
Peak force during the last close motion.
Description
UltraSync-E, If Equipped
Description
Minimum Maximum
0.01 mm 1.00 mm
Default
0.10 mm
