Fault
Number
Drive Fault (Error Code #)
Fault
1 Watchdog error
2 Incorrect interrupt has occurred
3 NMI interrupt/bus error
16 Errors while booting
17 Software error
18 Time slot configuration
19 Time slot – time error
20 No free memory
21 Invalid error code
22 Invalid warning code
23 False FPGA version
48 Error in module A
50 Error in module C
51 Error in module D
53 Error in module G
54 Error in module H
64 Mains failure
65 Phase failure
66 Mains under voltage
67 Mains over voltage
68 Under voltage 24 V
v 1.1 — July 2015
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Internal error. Cycle power to the drive.
Contact Husky Service.
Cycle power to the drive, check wiring to
module, replace module.
Cycle power to the drive, check wiring to
module, replace module.
Cycle power to the drive, check wiring to
module, replace module.
Cycle power to the drive, check wiring to
module, replace module.
Check that module switch is in the down
position, cycle power to the drive, contact
Husky Service.
Check fuses/circuit breaker, restore main power
to the drive.
Check fuses/circuit breaker, restore main power
to the drive.
Check power wiring. Measure voltage at the
drive, Phase to Phase must be greater than
208 V, correct low voltage condition.
Check power wiring. Measure voltage at the
drive, Phase to Phase must be less than 415 V,
correct low voltage condition.
Check DC power supply G1 wiring. Measure DC
voltage, must be between 20.4 V to 28.8 V, and
adjust if necessary.
UltraSync-E, If Equipped
Solution
