Husky Altanium Matrix2 User Manual page 33

User Guide
Bake Out Cycle 2
Bake Out Cycle 3
Bake Out Cycle 4
Bake Out Cycle 5
Soft Start
Soft Start to Manual
Standby
Soft Start to Remote
Standby
Stage x Active (Heating) All zones assigned to stage x (1-4) are heating to the stage setpoint.
Stage x Active (ART)
Stage x Soaking
(Heating)
Stage x Active (Cooling) All zones assigned to stage x are cooling to the stage setpoint.
Stage x Soaking
(Cooling)
Stage 4 Running
Indefinitely
Bake Out Check
Earth Leakage Check
Circuit Test
System Modes
System Mode
The system is baking out moisture in the mold. This is the second
attempt.
The system is baking out moisture in the mold. This is the third attempt.
The system is baking out moisture in the mold. This is the fourth attempt.
The system is baking out moisture in the mold. This is the fifth attempt.
The system is heating all zones up to setpoint in a gradual and even
manner.
The user pressed the manual standby button while the system was in the
soft start process.
While the system was in the soft start process, an external signal was
activated to attempt to heat all zones up to the remote standby setpoint.
The ART process is running on only the zones assigned to stage x.
After heating up, the system will maintain the stage x setpoint until the
soak timer expires.
After cooling down, the system will maintain the stage x setpoint until
the soak timer expires.
The system will remain in stage 4 until the user presses the Start button
to heat the zones to the normal setpoint.
The system is searching for any bake out conditions on any zone. These
bake out conditions would be less severe than a earth leakage.
The system is searching for any earth leakage conditions on any zone.
The system is verifying that there are no heater circuit faults (open circuit,
short circuit, leakage or wrong heater) on any zones.
v 1.1 — July 2015 Altanium Operator Interface
Description
21
