Table 10-7 Zone Alarm Control Settings (Continued)
No Response Limit
At Temperature Minimum Limit

10.1.17 Mold Cooling Enable

The Mold Cooling Enable Limit defines the threshold the system uses to determine when to
activate or deactivate the Mold Cooling Enable output.
Digital output 5 is activated when this output's In Use checkbox is selected and all automatic
zones have exceeded the Mold Cooling Enable Limit. This output is de-activated once the
system is in the 'Stop' state and all automatic zones have cooled down past the same limit.
To set the Mold Cooling Enable value, do the following:
1.
2.
3.
Mold Cooling Enable
Setting
On the System Setup screen, under Mold Cooling Enable, touch the Mold Cooling
Enable field.
Enter the desired value.
Touch the Accept button.
v 1.1 — July 2015
This is a global setting that determines how
long the system should apply 96% power or
greater without a 5 degree rise in
temperature before it is declared an alarm
condition. The default value is 4 minutes
and the valid range is 2 to 15 minutes.
This value defines the minimum threshold
for activating the At-Temperature signal.
The At-Temperature signal is activated
based on following:
When all active zone temperatures are
higher than the lower alarm limit.
If the alarm band setting is lower than the
At-Temperature Minimum Limit value, then
the At-Temperature Minimum Limit value is
used to activate the At-Temperature signal.
System Setup Screen
Description
133
