Monitoring
Position Alarm If the position of the valve stems deviates from the
Window set position by more than this amount, the alarm
"Position Deviation Limit Exceeded" is generated.
Position is monitored both during motion and
when holding at the open or close position.
Force Warning Level The force level at which a warning is generated.
The force warning level is calculated as a
percentage of the Opening or Closing force limit.

16.4.2 Other Settings

In the Other Settings section, configure the relax settings and use the At Temperature
Soak Time field to set the soak time. Select Enter Engaged Mode After Calibration as
required.
Relax Force Limit
Relax Delay
At Temperature
Soak Time
Enter Engaged
Mode After
Calibration
Curves Include
Accelerating Forces

16.4.3 Setup Buttons

Use the Setup buttons to open and configure the following UltraSync-E screens:
•
•
•
•
196
Description
Item
The force limit used after the Relax Delay has expired. This force limit should
be set lower than the operating force limits. Its purpose is to reduce energy
consumption and prevent overheating of the servo system and motor
during long idle periods. Minimum 0 kN, Maximum per tool, Default 10 kN.
The delay time before the Relax Force Limit is applied. The timer begins at
the end of the previous motion. Minimum 0 s, Maximum 120 s, Default 60 s.
Valve stems cannot be actuated until the soak time countdown has
completed. The soak time begins when the At Temperature status is true.
The first field displays the soak time remaining. The second field displays the
duration of the soak timer.
If selected, UltraSync will immediately enter Engaged mode after calibration
completes.
If selected, the force curves will display the total force, including the force
component used to accelerate and decelerate the inertial mass of the
UltraSync-E mechanism. This option changes the curves only and does not
affect the actual force or logged force.
Signals screen
Maintenance screen
Tool screen
Pullback screen
v 1.1 — July 2015
0.01 mm
0%
Description
Minimum Maximum
1.00 mm
100%
Altanium Matrix2
Default
0.05 mm
90%
Other Settings
