Chapter 11 Mold Picture View

This chapter describes how to use the mold picture view.

11.1 Loading a Mold Picture View Graphic

Load a mold picture view graphic from one of the following locations:
•
•
•

11.1.1 Mapping a Network Drive

If loading a mold picture view graphic from the network, make sure Altanium is mapped to a
valid network drive.
To map a network drive, do the following:
1.
2.
11.1.2 Loading a Mold Picture View Graphic
Altanium is capable of displaying up to five different images in the mold picture view. Use
this procedure to upload new mold picture view graphics.
To load a mold picture view graphic, do the following:
1.
Loading a Mold Picture View Graphic
the local drive
a USB drive
the network
On the Home screen, touch the Network Setup button.
In the Network Locations field, type a valid network location.
On the Home screen, touch the Mold Picture View button.
NOTE: If changing an existing mold picture view graphic, touch the name of the view
containing the mold picture view graphic to be changed.
v 1.1 — July 2015 Mold Picture View
141
