4.1.7 Shortcut Buttons

The Altanium shortcut buttons provide a link to the Quick Set screen for those zones that are
assigned to the associated group represented by the button. A maximum of ten shortcut
buttons
Table 4-3
Shortcut Button

4.1.7.1 Creating a Shortcut Button

To create a shortcut button, do the following:
On the Quick Set screen, select a group of zones. Touch the Group Name parameter and
assign a group name to the selected zones. For each group created, a shortcut button
appears on the Home screen. For more information about creating a group, refer to
Section

4.1.8 Screen Buttons

The Home screen provides a single area for a user to navigate to all other screens in the
system. The Home screen can be accessed from any other screen in the system by touching
the Home button in the System Header.
Table 4-4
Common Screens
Shortcut Buttons
v 1.1 — July 2015
can be displayed at once on the Home screen.
Shortcut Button
Touch the shortcut button to open the Quick Set screen and
automatically select the zones assigned to the group associated to the
shortcut.
7.2.
Screen Buttons
Screen
Alarms
Event History
Altanium Operator Interface
Description
Description
