16.4.3.2 Maintenance

Use the Maintenance dialog box to configure the maintenance position for Generation 1
tools.
The Maintenance position is user-adjustable, to a maximum of 20 mm. The default setting is
16.4 mm.
The Velocity setpoint to reach maintenance position is user-selectable, to a maximum of 5
mm/s. The default setting is 1mm/s.
The maintenance position command button and settings will be accessible only when
logged in with the appropriate security level.
Figure 16-5 Maintenance Dialog Box
Maintenance
v 1.1 — July 2015
Description
Valve stems open after the
Open Command signal is
active and the stem open
delay timer is complete. Valve
stems stay open until the stem
close delay timer is complete.
Valve stems open after the
Open Command signal is
active and the stem open
delay timer is complete. Valve
stems stay open until the
Close Command signal is
active and the stem close
delay timer is complete.
UltraSync-E, If Equipped
Open Valve Stems Close Valve Stems
Command
Examples
• Clamp closed
• Mold close
• Machine nozzle
shutoff
• Configurable
output
• Clamp closed •
• Mold close •
• Machine nozzle
shutoff
• Configurable
output
Command
Examples
—
Hold
Valve Gate Close
199
