Chapter 12 Data Recording

Data Recording is a useful tool to track the operation of a mold. This tool helps analyze the
system to optimize the molding process, track errors, find the source of a recent error or
predict where future errors may occur. The Error Log contains a record of errors that have
occurred since the errors were last cleared. Use the Process History screen to view the
operation of a mold and view recorded data. If an error has occurred while the system was
recording, review the behavior of the system at the time of the error to search for potential
causes.

12.1 Process Trend Screen

The Process Trend screen displays the following information:
•
•
•

12.1.1 Viewing the Process Trend

To change the zone or process displayed on the Process Trend screen, do the following:
1.
Process Trend Screen
The last 400 samples on four charts, where the X axis is the sample number and the Y
axis is the value of the sampled variable.
The data available for a selected variable.
The timestamp and value for any point on a graph.
On the Process Trend screen, touch the Variable Selection button.
