To change the energy usage and units, do the following:
1.
2.
3.
10.1.5 Changing the Grid Size and the Group Offset
To change the layout on the Card Layout screen, change the grid size. To configure the
linked systems, change the group offset setting. The default group offset setting is 96 zones.
To change grid size, do the following:
1.
2.
3.
4.
5.
10.1.6 Changing the Number of Zones in the System
Users may need to add or remove zones to an existing mold setup. If the mold running has
fewer control zones than listed on the Altanium screen, users can remove the unused zones
to make sure they are not displayed.
To change the number of zones in the system, do the following:
1.
2.
3.
4.
5.
10.1.7 Standby Timer Settings
To reduce the temperatures in the mold for a certain period of time, set the standby timers
associated with each standby function. Once the system enters standby, the timer will start.
When the timer finishes, the temperatures will return to the normal setpoint.
10.1.7.1 Setting the Manual Standby Duration Timer
The zone temperature decreases for a given time duration or until a set standby temperature
is achieved.
Changing the Grid Size and the Group Offset
On the System Setup screen, under Energy Usage and Units, touch the Energy Cost
Rate (Kwh) or Currency Type button as desired. A dialog box will open.
Change the desired units.
Touch the Exit button.
On the System Setup screen, under Zone Slot Configuration, touch the Grid Size
field.
Touch the desired grid size button.
Touch the Group Offset field.
Touch the desired group offset button.
Touch the Accept button.
On the Home screen, touch the Zone Slot button.
Select the number of zones and/or slots to be enabled or disabled.
Touch the Slot Enable button.
Touch the Accept button.
Restart the Altanium controller.
v 1.1 — July 2015
System Setup Screen
115
