Purpose Of The Equipment; Restrictions Of Use; Input Wiring (Conventional) - Husky Altanium Matrix2 User Manual

User Guide
Safety Symbol
1.2

Purpose of the Equipment

Husky controllers are designed to control the process temperature for injection molding
applications only.
Contact your nearest Husky Regional Service and Sales office if you plan to use a Husky
product for anything other than its intended use.
1.3

Restrictions of Use

Husky injection molding equipment must never be:
•
•
1.4

Input Wiring (Conventional)

The following table summarizes the wiring conventions used.
Neutral
Earth/Ground
Line
Purpose of the Equipment
General
This symbol indicates a potential personal injury hazard. It is usually
accompanied by another pictogram or text to describe the hazard.
Hazardous Voltage
This symbol indicates a potential hazard that may cause death or serious injury
and will appear on any panel that, if removed, will expose the user to more
than 40 VAC.
used for any purpose other than that described in
approved by Husky
operated or serviced by personnel unfamiliar with the inherent risks and necessary
precautions related to controllers
Description
v 1.1 — July 2015
General Description of Symbol
Green
Black
Section 1.2, unless otherwise
Wire Color
Blue
Green/Yellow
Black
Introduction
3
