4.1.6 View Buttons

The Altanium views display zone data in various formats.Touch the desired view
open the associated view screen.
Table 4-2
22
v 1.1 — July 2015
Views Buttons
View Button
Touch the Neo2 View button to display the Neo2 View screen.
Touch the Multi Group View button to display the Multi Group View
screen, which contains zones organized into groups and allows
individual control of each group.
Touch the Graphical View button to display the Graphical View screen,
which contains a graphical representation of zone data.
Touch the Text View button to display the Text View screen, which
contains a textual representation of zone data.
Touch the Mold Picture View button to display the Mold Picture View
screen, which provides a visualization of the mold or hot runner system
layout using an imported image file.
Description
Altanium Matrix2
to
button
View Buttons
