User Guide
Regulation
Man
Mon
To change the zone regulation, do the following:
1.
CAUTION!
If a zone is placed in Monitor mode by mistake, the system will give no power output
to that heater.
2.

7.5.16 Setpoint Limits

Altanium allows users to set a specific range where the operator is prevented from changing
the setpoint beyond these limits.

7.5.16.1 Changing the Normal Setpoint and Limits

On the Quick Set screen, in the Setpoint Limits section, specify the temperatures to heat the
heaters in the mold. The default setting is 177 °C (350 °F).
To change a normal setpoint and setpoint limits for a zone, do the following:
1.
2.
3.
4.
5.
6.
7.
8.
9.

7.5.16.2 Changing the Manual Standby and Remote Standby Setpoint Limits

It may be necessary to lower the temperatures in the mold for a period of time. This can be
done on the system header by selecting the Manual Standby button (or Remote Standby
from a remote location as an option) without needing to change the normal setpoint. Specify
Setpoint Limits
Mode
In
Manual
100%) to the heater and not look for sensor feedback.
In
Monitor
thermocouple (no power output).
On the Quick Set screen, touch the zone to be changed.
Touch the Regulation Mode field. A dialog appears with the three mode choices The
user can either select one of them or cancel the operation.
Touch the zone to change.
Touch the Temperature Minimum field and enter a value.
Touch the Accept button.
Touch the Temperature Maximum field and enter a value.
Touch the Accept button.
Touch the Power Minimum field and enter a setpoint value.
Touch the Accept button.
Touch the Power Maximum field and enter a setpoint value.
Touch the Accept button.
v 1.1 — July 2015
Description
(open loop) mode, the system will only apply power (0 to
mode, the system will only monitor the temperature of a
Making Adjustments
