Table 6-2

6.1.1 Creating a New Mold Setup Folder

Use a Mold Setup folder to store multiple mold setup files.
To create a new Mold Setup folder, do the following:
1.
2.
3.

6.1.2 Creating a New Mold Setup File

Once a Mold Setup folder has been created, a new mold setup file can be added to it.
When a new mold setup file is created, and the Default folder contains only the Default mold
setup file, the factory default setup file is copied and used as a starting point.
If the Default folder contains a user supplied setup file named "New Setup", the new setup
file is a copy of the 'new setup' file. The user can create this 'New Setup' file by first copying
Creating a New Mold Setup Folder
Mold Setup Screen Button Descriptions (Continued)
Button
Touch the Discard Changes button to revert the currently loaded mold
setup file to the state after it was last saved (using the Save Mold Setup
button). All unsaved changes will be discarded. This action only pertains to
the loaded mold setup file regardless of what is selected on the screen.
Touch the Copy button to copy mold setups, images or documents from
one folder or device to another.
Touch the Paste button to paste mold setups, images, documents or notes
from one folder or device to another.
Touch the Delete button to delete a mold folder, mold setup, image or
document. A confirmation message is shown. This button is not available
unless a folder or file is selected.
Touch the Rename button to display a keyboard to rename a mold folder,
mold setup, image, note or document. This button is not enabled unless a
file or folder is selected.
Touch the Preview button to display mold setup files, images, notes and
documents.
Touch the New Folder button.
Enter the name of the new mold folder.
Touch the Accept button.
The new Mold Setup folder is now displayed under the Molds directory.
v 1.1 — July 2015
Description
Mold Setups
53
