Table 10-6 Power Deviation Settings
Power Deviation Enable
Sample Period
Stabilization Time
Deviation Limit Field
Baseline Average Relearn Button
Baseline Established Status Field
122
v 1.1 — July 2015
Setting Description
Toggles the feature on or off.
Defines the amount of time the system will
take to establish a baseline average power
value (i.e. learn the mold). The default value
is 2 minutes and the range is from 1-10
minutes.
Defines the amount of time the system will
take, after all active zones have reached
setpoint, before it will initiate the Sample
(learning) Period. The default value is 2
minutes and the range is from 1-10 minutes.
This field is used by the system to determine
the tolerance value that will be used for
declaring an error. This value will only be
used if the value calculated by the system
cannot be used. The default value is 10%
and the range is from 1-100% definable in
1% increments. This field is not accessible
unless the user logs in and sets the
controller function to true in the
screen and enables security.
Profiles
This button is used to start a new sample
period in cases where the original sample
time was not sufficient to establish good
baseline average power values. This button
is a manual override that should only be
active after all active zones have reached
setpoint and the Stabilization Time has
expired.
This field is used to determine if a baseline
has already been done for the currently
loaded mold setup.
