Table 4-1

4.1.5 System Modes

The system mode is displayed in the status bar on each screen.
Stop
Running
Manual Standby
Remote Standby
Delay Standby
Manual Boost
Remote Boost
Delay Boost
ART
Calibration
Diagnostics
Firmware Update
Bake Out Cycle 1
20
Dialog Box Buttons
Screen
Accept
Cancel
Exit
System Mode
The system is stopped and no power is being applied to the heaters.
The system is heating up to or maintaining the normal setpoint.
The user pressed the Manual Standby button and the system is heating
to the manual standby setpoint.
An external signal has activated the remote standby mode and the
system is heating up to the remote standby setpoint.
The system is delaying for a set period of time before entering the remote
standby mode.
The user pressed the Manual Boost button and the system is heating to
the manual standby setpoint.
An external signal has activated the remote boost mode and the system
is heating up to the remote boost setpoint.
The system is delaying for a set period of time before entering Remote
Boost mode.
The Active Reasoning Technology (ART) tuning process is active.
A user is calibrating the thermocouple inputs for each zone.
The mold diagnostics process is active.
A firmware update is in process on the selected control cards.
The system is baking out moisture in the mold. This is the first attempt.
v 1.1 — July 2015
Description
Description
Altanium Matrix2
System Modes
