User Guide
Mold Diagnostics
Rewire
Cross-Talk
Temperature Graphs
Start Time
Elapsed Time

8.2.1 Test Results Screen Values

The following section describes the fields and buttons on the Test Results screen.
Zone
Name
Sen.
Fuses
T/C
AMP
VAC
Watt
OHM
Test Results Screen Values
v 1.1 — July 2015
Item
Opens the Mold Diagnostics screen.
Automatically reassigns all the sensors to their proper location based on
the results of the test.
Opens the Cross-Talk screen.
Opens the Temperature Graphs screen.
Time the most recently conducted test was started.
Duration of the most recently completed test.
Item
Zone number
Zone name
Indicates the number of the sensor being used for that zone.
The fuses test will determine whether the fuse for that zone is operating
correctly. Fuse values are displayed as follows:
• Question Mark: indicates the fuse for the zone was not tested.
• Check Mark: indicates the fuse for the zone passed the test.
• X: indicates the fuse for the zone failed the test.
The thermocouple test will determine whether the thermocouple for
that zone is operating correctly. Thermocouple values are displayed as
follows:
• Question Mark: indicates the thermocouple for the zone was not
tested.
• Check Mark: indicates the thermocouple for the zone test passed.
• X: indicates the thermocouple for the zone failed the test because it
was reversed or lost.
Current drawn by the heater during the test for each zone.
Line voltage reading taken during the test for each zone.
Power calculated for each zone based on the line voltage and current
readings measured during the test.
Resistance calculated for each zone based on the line voltage and current
readings measured during the test.
Description
Description
Mold Diagnostics
