Table 13-1 Digital I/O Screen Item Descriptions (Continued)
Pins
Normally
In Use
Active
To configure the digital I/O, do the following:
1.
2.

13.1.1 Turning an I/O Option On or Off

The system comes standard with the ability to configure up to 4 I/O options. If an option
package is included with the system, desired options must be turned on. The system will only
allow the number of options purchased to be turned on. To try a different option once the
purchase limit has been reached, turn one of the options OFF before turning another option
ON.
To turn an option on or off, do the following:

13.2 Cable Connections

With the exception of the USB connection on the front of the Matrix2 display, all cables are
connected to the back of the Matrix2 display.
The insulation level of control cables and devices connected to Matrix2 I/O's shall be as
follows:
NOTE:
164
Item
The connector pins associated with each input and output.
Inputs normally refer to the state of the external dry contact. Outputs
normally refer to the state of the internal relay switch. The relay switch
may be closed or opened when the output is active.
Used to turn the option on or off.
Indicates if the feature is active (green) or inactive (grey).
On the Home screen, touch the Digital I/O button.
Configure the settings according to requirements.
To turn the option on, select the In Use check box for the option to turn on.
To turn the option off, clear the In Use check box for the option to turn off.
500V when the devices are powered by a 400VAC or 415VAC system;
300V when the devices are powered by a system up to 240VAC.
When the 24V provided on Input, Part Count or Remote Load connectors is
connected to external devices, the total current used by all external devices shall not
exceed 1A.
v 1.1 — July 2015
Description
Turning an I/O Option On or Off
Altanium Matrix2
