User Guide
Limit
Stop Controller
Digital Output On
Delay Limit Check

12.3.1 Filtering by Units

To filter based on units of measure, do the following:
1.
Figure 12-9 Units Filter Dialog Box
2.
3.
Filtering by Units
Definition
If selected, the controller will stop if any critical process variable is not within
the lower and upper limits.
If selected, a digital output will trigger if any process variable is not within the
lower and upper limits. For more information, refer to the Digital I/O screen.
If selected, process targets will not be checked until all zones are at
temperature. The timer then will start. Once the time expires, the targets will
be checked according to their settings.
On the Process Target screen, touch the Units Filter field. The Units Filter dialog box
appears.
Touch the desired unit of measure.
Touch the Close button.
v 1.1 — July 2015 Data Recording
161
