7.5

Quick Set Screen

Use the Quick Set screen to change any of the available zone settings. On the Home screen,
touch the Quick Set button.
Figure 7-7 Quick Set Screen

7.5.1 Frequently Used Fields

Temperature Setpoint
Power Setpoint
Zone On/Off
Regulation Mode
66
v 1.1 — July 2015
Item
Touch this field to display a keypad for adjusting a zone(s) setpoint in
Auto or Monitor regulation.
Touch this field to display a keypad for adjusting the percentage of
power output when a zone(s) is in Manual regulation.
Touch this field to turn the selected zone ON or OFF. A dialog appears and
allows the user to choose a value. The default is ON.
This setting allows users to set the regulation mode for the selected zone.
AUTO or Automatic (closed loop) means the system will use a
thermocouple to control the temperature. MAN or Manual (open loop)
means the system will only apply power (0 to 100%) to the heater and not
look for thermocouple feedback. MON or Monitor means the system will
only monitor the temperature of a thermocouple (no power output).
Description
