11.3.2.3 Editing a Zone Information Panel

In addition to the zone number, a zone information panel also contains two of the following
pieces of information:
•
•
•
•
•
NOTE:
To change the content displayed on a zone information panel, do the following:
1.
2.
3.
Figure 11-8 Mold Picture View Screen in Edit Mode
1. Change View Settings Button 2. Choose Heat Zone Button 3. Leader Line Color Button
4. Mold Picture View Graphic 5. Leader Line 6. Zone Information Panel 7. Delete Button
8. Accept Button
148
Zone Name
Current Temperature Setpoint
Actual Temperature
Power Output
Amperage
Actual earth leakage is an option when ICC
leakage parameter is set.
Make sure Mold Picture View is in Edit mode.
On the Mold Picture View screen, touch the Zone Information Panel to be changed.
Touch the Change View Settings button.
1
2
3
4
5
6
v 1.1 — July 2015
3
cards are installed and the display earth
Editing a Zone Information Panel
Altanium Matrix2
7
8
