Table 7: GTM_DUAL Clocking Ports
Port
PLLREFCLKSEL[2:0]
GTGREFCLK2PLL
GTREFCLK
GTNORTHREFCLK
GTSOUTHREFCLK
PLLREFCLKLOST
PLLREFCLKMONITOR

LCPLL

Each Dual contains one LC-based PLL, referred to as LCPLL, and cannot be shared with
neighboring Duals. The internal clocking architecture of the GTM Dual is shown in the following
figure.
UG581 (v1.0) January 4, 2019
Virtex UltraScale+ GTM Transceivers
Direct Clock
ion Domain
In Async Input to dynamically select the input reference clock to the
LCPLL. Set this input to 3'b001 and connect to GTREFCLK when
only one clock source is connected to the PLL reference clock
selection multiplexer:
3'b000: Reserved.
3'b001: GTREFCLK selected.
3'b010: Reserved.
3'b011: GTNORTHREFCLK selected.
3'b100: Reserved.
3'b101: GTSOUTHREFCLK.
3'b110: Reserved.
3'b111: GTGREFCLK2PLL.
In Clock Reference clock generated by the internal interconnect logic.
This input is reserved for internal testing purposes only.
In Clock External clock driven by IBUFDS_GTM for the LCPLL.
In Clock Northbound clock from the Dual below.
In Clock Southbound clock from the Dual above.
Out Async A High on this signal indicates that the reference clock to the
phase frequency detector of the LCPLL is lost.
Out Clock LCPLL reference clock selection multiplexer output.
