Polycom® RealPresence Collaboration Server (RMX) 1500/2000/4000 Administrator's Guide
•

MCU Supported Resolutions for SVC Conferencing

The MCU automatically selects the resolution and frame rate according to the conference
line rate. Table 2-6 details the maximum resolution and frame rates supported by the MCU
for each conference line rate. The actual video rate, resolution and frame rates displayed on
each endpoints is determined by the endpoint's capabilities.:
Table 2-6
Conference Line Rate
(kbps)
1472 - 2048
1024 - 1472
768 - 1024
512 - 768
256 - 512
192 - 256
128 - 192
2-16
The following functionality and features are not supported during SVC Only
conferences:
— FECC
— Skins. The video cells are displayed on the endpoint's default background.
— IVR functionality
— Conference Gathering phase
— Password protected conferences as DTMF input for passwords cannot be
processed
— All DTMF enabled features during the conference
— Manual selection of video layout
— Chairperson functionality
— Media Encryption
— Recording of SVC Only conferences
— Text messaging using Message Overlay
SVC Conferencing - Maximum Supported Resolutions per Simulcast Stream
Profile
High Profile
High Profile
High Profile
High Profile
Base Profile
Base Profile
Base Profile
Maximum Max. Frame
Resolution Rate (fps)
720p 30fps
720p 15fps
720p 15fps
360p 30fps
180p 15fps
180p 30fps
180p 15fps
Audio Rate
(kbps)
48
48
48
48
48
48
48
