Polycom® RealPresence Collaboration Server (RMX) 1500/2000/4000 Administrator's Guide
•
•

Resolution Configuration for CP Conferences

The Resolution Configuration dialog box enables you to override the default video resolution
decision matrix, effectively creating your own decision matrix. The minimum threshold line
rates at which endpoints are connected at the various video resolutions can be optimized by
adjusting the resolution sliders.
System resource usage is also affected by the Resolution Configuration settings. For more
information see "Video Resource Usage" on page
Rates and Resource Usage Summary" on page 3-12.
Guidelines
•
On the RealPresence Collaboration Server (RMX) 1500 MPMx-Q assembly, the use of HD with
Continuous Presence requires an additional license. In the Resource Report and Resolution
Configuration panes, HD settings are displayed but are not enabled and if HD is selected the system
will enable SD by default.
•
•
From Version 7.1, MPM media cards are not supported.
From Version 8.1, MPM+ media cards are not supported.
Accessing the Resolution Configuration Dialog Box
The Resolution Configuration dialog box is accessed by clicking Setup > Resolution
Configuration in the RMX Setup menu.
The Resolution Configuration dialog box display changes according to the Card Configuration
Mode:
•
•
3-14
The table above lists resource consumption for H.264.
For H.263 with MPMx cards:
•
CIF resolution consumes 1.5 resources.
•
4CIF resolution consumes 3 resources.
Resolution Slider settings affect all Continuous Presence (CP) conferences running on the
RMX. Video Switched conferences are not affected.
A system restart is not needed after changing the Resolution Slider settings.
Resolution Slider settings cannot be changed if there are ongoing conferences running on
the RMX. The displayed sliders and the resolutions change according the Card
Configuration Mode: MPM, MPM+ or MPMx.
MPM and MPM+
MPMx - supports H.264 High Profile
3-5 and "Default Minimum Threshold Line
