4.10.4 ACL Ports Configuration

Configure the ACL parameters (ACE) of each switch port. These parameters will affect frames received on a port unless the frame
matches a specific ACE. The ACL Ports Configuration screen in
The Page includes the following fields:
Object

Port

Policy ID

Action

Rate Limiter ID
Figure 4-10-4: ACL Ports Configuration Page Screenshot
Description
The logical port for the settings contained in the same row.
Select the policy to apply to this port. The allowed values are 0 through 255.
The default value is 0.
Select whether forwarding is permitted ("Permit") or denied ("Deny").
The default value is "Permit".
Select which rate limiter to apply on this port. The allowed values are Disabled or
the values 1 through 16.
Figure 4-10-4 appears.
