Interlogix NS4702-24P-4S-4X User Manual page 332

The Page includes the following fields:
LLDP Parameters
Object

Tx Interval

Tx Hold
Figure 4-14-1: LLDP Configuration Page Screenshot
Description
The switch is periodically transmitting LLDP frames to its neighbors for having the
network discovery information up-to-date. The interval between each LLDP
frame is determined by the Tx Interval value. Valid values are restricted to 5 -
32768 seconds.
Default: 30 seconds
This attribute must comply with the following rule:
(Transmission Interval * Hold Time Multiplier) ≤65536, and Transmission Interval
>= (4 * Delay Interval)
Each LLDP frame contains information about how long the information in the
332
