4.1 Main Web Page

The Managed Switch provides a Web-based browser interface for configuring and managing it. This interface allows you to access
the Managed Switch using the Web browser of your choice. This chapter describes how to use the Managed Switch's Web browser
interface to configure and manage it.
Main Functions Menu
Help Button
Panel Display
The web agent displays an image of the Managed Switch's ports. The Mode can be set to display different information for the ports,
including Link up or Link down. Clicking on the image of a port opens the Port Statistics Page.
The port status are illustrated as follows:
Main Menu
Using the onboard web agent, you can define system parameters, manage and control the Managed Switch, and all its ports, or
Copper Port Link Status
Figure 4-1-4: Web Main Page
State Disabled
RJ-45 Ports
SFP Ports
Down
42
SFP/SFP+ Port Link
Main Screen
Link
