Figure 4-8-9: IGMP Snooping Port Filtering Profile Configuration Page Screenshot
The Page includes the following fields:
Object

Port
 Filtering Profile
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.

4.8.7 IGMP Snooping Status

This Page provides IGMP Snooping status. The IGMP Snooping Status screen in
Description
The logical port for the settings.
Select the IPMC Profile as the filtering condition for the specific port. Summary
about the designated profile will be shown by clicking the view button
176
Figure 4-8-10 appears.
