4.16 Power over Ethernet

Providing up to 24 PoE, in-line power interfaces, the NS4702-24P-4S-4X PoE Switch can easily build a power central-controlled
IP phone system, IP Camera system, AP group for the enterprise. For instance, 24 camera / AP can be easily installed around the
corner in the company for surveillance demands or build a wireless roaming environment in the office. Without the power-socket
limitation, the NS4702-24P-4S-4X PoE Switch makes the installation of cameras or WLAN AP more easily and efficiently.

4.16.1 Power over Ethernet Powered Device

3~5 Watts
6~12 Watts
10~12 Watts
Figure 4-16-1: Power over Ethernet Status
Voice over IP phones
Enterprise can install POE VoIP Phone, ATA and other
Ethernet/non-Ethernet end-devices to the central where UPS is installed for
un-interrupt power system and power control system.
Wireless LAN Access Points
Museum, Sightseeing, Airport, Hotel, Campus, Factory, Warehouse can
install the Access Point any where with no hesitation.
IP Surveillance
Enterprise, Museum, Campus, Hospital, Bank, can install IP Camera
without limits of install location – no need electrician to install AC sockets.
359
