Interlogix NS4702-24P-4S-4X User Manual page 186

Figure 4-8-15: MLD Snooping Port Group Filtering Configuration Page Screenshot
The Page includes the following fields:
Object
 Port
 Filtering Group
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
Description
The logical port for the settings.
Select the IPMC Profile as the filtering condition for the specific port. Summary
about the designated profile will be shown by clicking the view button.
186
