Buttons
: Click to refresh the Page immediately.
Auto-refresh : Automatic refresh occurs every 3 seconds.

4.5.5 LACP Port Statistics

This Page provides an overview for LACP statistics for all ports. The LACP Port Statistics screen in
The Page includes the following fields:
Object

Port

LACP Received

LACP Transmitted

Discarded
Figure 4-5-7: LACP Statistics Page Screenshot
Description
The switch port number.
Shows how many LACP frames have been sent from each port.
Shows how many LACP frames have been received at each port.
Shows how many unknown or illegal LACP frames have been discarded at each
port.
111
Figure 4-5-7 appears.
