Enabled
 RADIUS-Assigned
VLAN Enabled
for a given port, the switch reacts to QoS Class information carried in the
RADIUS Access-Accept packet transmitted by the RADIUS server when a
supplicant is successfully authenticated. If present and valid, traffic received on
the supplicant's port will be classified to the given QoS Class. If
(re-)authentication fails or the RADIUS Access-Accept packet no longer carries a
QoS Class or it's invalid, or the supplicant is otherwise no longer present on the
port, the port's QoS Class is immediately reverted to the original QoS Class
(which may be changed by the administrator in the meanwhile without affecting
the RADIUS-assigned).
This option is only available for single-client modes, i.e.

Port-based 802.1X

Single 802.1X
RADIUS attributes used in identifying a QoS Class:
The User-Priority-Table attribute defined in RFC4675 forms the basis for
identifying the QoS Class in an Access-Accept packet.
Only the first occurrence of the attribute in the packet will be considered, and to
be valid, it must follow this rule:
 All 8 octets in the attribute's value must be identical and consist of ASCII
characters in the range '0' - '7', which translates into the desired QoS Class
in the range [0; 7].
When RADIUS-Assigned VLAN is both globally enabled and enabled (checked)
for a given port, the switch reacts to VLAN ID information carried in the RADIUS
Access-Accept packet transmitted by the RADIUS server when a supplicant is
successfully authenticated. If present and valid, the port's Port VLAN ID will be
changed to this VLAN ID, the port will be set to be a member of that VLAN ID,
and the port will be forced into VLAN unaware mode. Once assigned, all traffic
arriving on the port will be classified and switched on the RADIUS-assigned
VLAN ID.
If (re-)authentication fails or the RADIUS Access-Accept packet no longer carries
a VLAN ID or it's invalid, or the supplicant is otherwise no longer present on the
port, the port's VLAN ID is immediately reverted to the original VLAN ID (which
may be changed by the administrator in the meanwhile without affecting the
RADIUS-assigned).
This option is only available for single-client modes, i.e.
