Fast Accessible Options - Comtech EF Data CDM-625 Installation And Operation Manual

CDM-625 Advanced Satellite Modem
Introduction
Available FAST and hardware options are as follows:
Option
IF band
Forward Error Correction
Data Rate (base function)
Data Rate (TPC/LDPC function)
Modulation
Open Network
Drop and Insert
®
DoubleTalk Carrier-in-Carrier
G.703 Clock Extension
BUC Power Supplies
Main Power Supply
1.4.1

FAST Accessible Options

Comtech EF Data's FAST system allows immediate implementation of different options through
the user interface keypad. All FAST options are available through the basic platform unit.
Description and Comments
50 – 180 MHz
950 – 1950 MHz (L-Band)
Viterbi and concatenated Reed-Solomon
LDPC/TPC Codec
Data rate 18 kbps to 5.0 Mbps
Data rate 18 kbps to 10.0 Mbps
Data rate 18 kbps to 15.0 Mbps
Data rate 18 kbps to 20.0 Mbps
Data rate 18 kbps to 25.0 Mbps
Data rate 18 kbps to 5.0 Mbps
Data rate 18 kbps to 10.0 Mbps
Data rate 18 kbps to 15.0 Mbps
Data rate 18 kbps to 20.0 Mbps
Data rate 18 kbps to 25.0 Mbps
BPSK, QPSK, OQPSK
8-PSK and 8-QAM
16-QAM
All IDR/IBS Open Network features
T1/E1 D&I (single port)
Quad E1 Drop and Insert
®
®
DoubleTalk Carrier-in-Carrier
Data rate 18 kbps to 512 kbps
Data rate 18 kbps to 1 Mbps
Data rate 18 kbps to 2.5 Mbps
Data rate 18 kbps to 5.0 Mbps
Data rate 18 kbps to 10.0 Mbps
Data rate 18 kbps to 15.0 Mbps
Data rate 18 kbps to 20.0 Mbps
Data rate 18 kbps to 25.0 Mbps
G.703 Clock Extension
24 volt, 100 watt
48 volt, 150 watt @ 50 degC (180 watt @ 35 degC)
115/230 volt AC
-48 volt DC
1–6
MN-0000036 (Ref MN/CDM625.IOM)
®
option card
Revision 1
Option
Installation
method
BASE UNIT
FAST
BASE UNIT
HARDWARE
BASE UNIT
FAST
FAST
FAST
FAST
BASE UNIT
FAST
FAST
FAST
FAST
BASE UNIT
FAST
FAST
FAST
FAST
FAST
HARDWARE
FAST
FAST
FAST
FAST
FAST
FAST
FAST
FAST
FAST
HARDWARE
HARDWARE
HARDWARE
HARDWARE
