6.3.3 SNMP Traps

The modem has the ability to send out SNMP traps when certain events occur in the modem. The
modem sends out traps when an alarm or a fault occurs in the modem. These include unit faults,
Tx faults, Rx faults, and ODU faults. A trap is sent both when a fault occurs and is cleared.
The modem supports both SNMPv1 traps and SNMPv2 notifications. Which style of traps the
modem sends can be configured by the user using the CDM750SNMPTrapVersion OID:
•
The CDM‐750 supports the following MIB2 SNMPv1traps / SNMPv2 notifications:
MIB2 SNMPv1 trap: Authentication Failure
MIB2 SNMPv2 notifications: Authentication Failure
•
The CDM‐750 supports the following Alarms and Faults SNMPv1 traps:
cdm750UnitAlarmV1
cdm750TxTrafficAlarmV1
cdm750RxTrafficAlarmV1
cdm750TrapStoredEventAlarm
cdm750RedundancySwitch
•
The CDM‐750 supports the following Alarms and Faults SNMPv2 notifications:
cdm750UnitAlarm
cdm750TxTrafficAlarm
cdm750RxTrafficAlarm
cdm750TrapStoredEventAlarm
cdm750RedundancySwitch
5
1.3.6.1.6.3.1.1.5.5
6247600
6247601
6247602
6247603
6247604
1.3.6.1.4.1.6247.55.2.1.1.1
1.3.6.1.4.1.6247.55.2.1.1.2
1.3.6.1.4.1.6247.55.2.1.1.3
1.3.6.1.4.1.6247.55.2.1.1.4
1.3.6.1.4.1.6247.55.2.1.1.5
