500 C 25: V
HAPTER OICE
Configuring the Voice
VLAN
Configuration
Prerequisites
Configuring Voice VLAN
under Automatic Mode
Configuring Voice VLAN
under Manual Mode
VLAN C
ONFIGURATION
It is recommended that you do not mix voice packets with other types of data in a
voice VLAN. If necessary, please ensure that the security mode is disabled.
Create the corresponding VLAN before configuring the voice VLAN;
■
As a default VLAN, VLAN 1 does not need to be created. However, it cannot be
■
enabled with the voice VLAN feature.
Follow the following steps to configure the voice VLAN under automatic mode:
To do...
Enter system view
Configure the aging time of
the voice VLAN
Enable the security mode of
the voice VLAN
Configure the OUI address for
the voice VLAN
Enable the global voice VLAN
feature
Enter Ethernet interface view
Configure the working mode
on a port as automatic
Enable the voice VLAN feature
on the interface
n
The default VLAN of a port in automatic mode cannot be configured as voice
■
VLAN. Otherwise, the system will prompt error information.
Issuing of the voice vlan security enable command and the undo voice
■
vlan security enable command only takes effect before the voice VLAN
attribute is enabled globally.
Follow the following steps to configure the voice VLAN under manual mode:
To do...
Enter system view
Enable the security mode of a
voice VLAN
Use the command...
system-view
voice vlan aging minutes
voice vlan security enable
voice vlan mac-address oui
mask oui-mask [ description
text ]
voice vlan vlan-id enable
interface interface-type
interface-number
voice vlan mode auto
voice vlan enable
Use the command...
system-view
voice vlan security enable
Remarks
-
Optional
Only applicable to ports in
automatic mode and defaults
to 1,440 minutes
Optional
Enabled by default
Optional
By default, each voice VLAN
has 8 default OUI addresses as
listed in Table 17.
Required
-
Optional
Automatic mode by default
The working mode of the
voice VLAN on each port is
independent of each other.
Required
Not enabled by default
Remarks
-
Optional
Enabled by default
