DNS Configuration
Examples
Static Domain Name
Resolution
Configuration Example
Dynamic Domain Name
Resolution
Configuration Example
Network requirements
Device uses the static domain name resolution to access Host with IP address
10.1.1.2 through domain name host.com.
Network diagram
Figure 178 Network diagram for static domain name resolution
10.1 .1.1/24
Device
Configuration procedure
# Configure a mapping between host name host.com and IP address 10.1.1.2.
<Sysname> system-view
[Sysname] ip host host.com 10.1.1.2
# Execute the ping host.com command to verify that the device can use the static
domain name resolution to get the IP address 10.1.1.2 corresponding to
host.com.
[Sysname] ping host.com
PING host.com (10.1.1.2):
56 data bytes, press CTRL_C to break
Reply from 10.1.1.2: bytes=56 Sequence=1 ttl=255 time=1 ms
Reply from 10.1.1.2: bytes=56 Sequence=2 ttl=255 time=4 ms
Reply from 10.1.1.2: bytes=56 Sequence=3 ttl=255 time=3 ms
Reply from 10.1.1.2: bytes=56 Sequence=4 ttl=255 time=2 ms
Reply from 10.1.1.2: bytes=56 Sequence=5 ttl=255 time=3 ms
--- host.com ping statistics ---
5 packet(s) transmitted
5 packet(s) received
0.00% packet loss
round-trip min/avg/max = 1/2/4 ms
Network requirements
The IP address of the DNS server is 2.1.1.2/16 and the DNS suffix is com.
■
Device serving as a DNS client uses the dynamic domain name resolution and
■
DNS suffix to access the host with the domain name being host.com and the IP
address 3.1.1.1/16.

DNS Configuration Examples

10 .1 .1.2/24
host.com
Host
