A H 5 0 0 H a r d w a r e a n d O p e r a t i o n M a n u a l

(5) Set the parameters in the Driver Properties window, and then click OK.

Type a driver name in the Driver Name box.

Select USB (Virtual COM) in the Type drop-down list box in the Connection Setup section.

Select a communication port in the COM Port drop-down list box. If the first two steps are complete,

the PLC which is connected and its communication port will be displayed in the COM Port drop-down

Users can select the number of times the sending of a command is retried if a connection error occurs

in the Connect Retries box, and select an interval of retrying the sending of a command in the

Connection Time-Out box.

(6) Check if the Status of Driver is OK, if it is ok, you can close the window. COMMGR is still running in the
