Delta AH500 Hardware Operation Manual page 198


USB port
Pin
1
2
3
4
5

Ethernet port
Pin
1
2
3
4
5
6
7
8
Function
VBUS (4.4–5.25 V)
D−
D+
Ground
Ground
Signal Description
Transmitting data
TX+
(positive pole)
Transmitting data
TX-
(negative pole)
Receiving data
RX+
(positive pole)
--
--
Receiving data
RX-
(negative pole)
--
--
C h a p t e r 4 I n s t a l l i n g H a r d wa r e a n d W i r i n g
N/C
N/C
N/C
N/C
4 - 3 1
