Alarm Types
GA Interface Alarms
Following are the alarms related to GA interface.
•

Connection to CGF failed

•

CDR transfer failed

• CDR generation failed
Connection to CGF failed
TABLE 81 Connection to CGF failed alarm
Alarm
Alarm Type
Alarm Code
Severity
Aggregation Policy
Auto Clearance
Attribute
Displayed on the web
interface
Description
Recommended Actions
CDR transfer failed
TABLE 82 CDR transfer failed alarm
Alarm
Alarm Type
Alarm Code
Severity
Aggregation Policy
Attribute
Displayed on the web
interface
Description
Recommended Actions
96
on page 96
on page 96
on page 97
Connection to CGF failed
cnxnToCgfFailed
1610
Major
From the event code 1610 an alarm is raised for every event. A single event
triggers a single alarm.
The alarm code is auto cleared with the event code 1613.
"mvnoId"="2", "ctrlBladeMac"="aa:bb:cc:dd:ee:ff",
"srcProcess"="cip", "realm"="NA", "radSrvrIp"="7.7.7.7",
"cgfSrvrIp"="40.40.40.40", "SCGMgmtIp"="2.2.2.2"
Connection with CGF [{cgfSrvrIp}] from RADServerIP [{radSrvrIp}] on
{produce.short.name} [{SCGMgmtIp}]
This alarm is triggered when the channel interface processor (CIP) or GPRS
tunneling protocol prime (GTPP) stack detects a connection loss to the charging
gateway function (CGF server.
Manual intervention is required. Refer to
1613. The attribute cgfSrvlp should match.
CDR transfer failed
cdrTxfrFailed
1614
Major
From the event code 1614 an alarm is raised for every event. A single event
triggers a single alarm.
"mvnoId"="2", "ctrlBladeMac"="aa:bb:cc:dd:ee:ff",
"srcProcess"="cip", "realm"="wlan.3gppnetwork.org",
"radSrvrIp"="7.7.7.7", "cgfSrvrIp"="40.40.40.40",
"CGF Serv Intf"="2.2.2.2","cause"="<reason for failure>"
CDR transfer failed from RAD Server [{radSrvrIp}] to CGF [{cgfSrvrIp}] on
{produce.short.name} [{SCGMgmtIp}]
This alarm is triggered when the call detail record transfer over Gn' fails.
Manual intervention is required. Check the web interface for the home location
register (HLR) configuration and also if the HLR can be reached from the
controller.
GA Interface Events on page 257 code
