Events Types
AP State Change Events
TABLE 295 AP NAT gateway IP fall back detected for particular VLAN pool event (continued)
Event
Event Code
Severity
Attribute
Displayed on the web
interface
Description
NAT VLAN capacity affected detected by NAT gateway AP at zone due
to three (3) consecutive NAT gateway AP IPs are down for particular
VLAN pool
TABLE 296 NAT VLAN capacity affected detected by NAT gateway AP at zone due to three (3) consecutive NAT gateway
AP IPs are down for particular VLAN pool event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description
NAT VLAN capacity restored detected by NAT gateway AP due to (at
least) one out of the three (3) consecutive NAT gateway AP IP were down
is now up
TABLE 297 NAT VLAN capacity restored detected by NAT gateway AP due to (at least) one out of the three (3)
consecutive NAT gateway AP IP were down is now up event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
186
AP NAT gateway IP fall back detected for particular VLAN pool
343
Informational
"vlanId"="1", "natGatewayMac"="xx:xx:xx:xx:xx:xx", "apMac"="xx:xx:xx:xx:xx:xx"
NAT fallback detected for VLAN [{vlanId}] by AP [{apMac}]. Bringing down
interface and switching traffic to AP [{natGatewayMac}].
This event occurs when any NAT gateway AP detects that other monitored NAT
gateway AP IP is up.
NAT VLAN capacity affected detected by NAT gateway AP at zone due to three
(3) consecutive NAT gateway AP IPs are down for particular VLAN pool
apNATVlanCapacityAffected
344
Critical
"natGatewayIP1"=192.168.10.2", "natGatewayIP2"=192.168.10.3", "nat
GatewayIP3"= 192.168.10.4","vlanId"="2", "apMac"="xx:xx:xx:xx:xx:xx"
NAT VLAN capacity affected is detected by NAT gateway AP [{apMac}] since
three (3) consecutive NAT gateway IPs
[{natGatewayIP1&&natGatewayIP2&&natGatewayIP3}] are down. The NAT traffic
for some of the clients may get affected for VLAN [{vlanId}].
This event occurs when NAT VLAN capacity affected is detected by NAT gateway
AP at zone. This is due to three (3) consecutive NAT gateway AP IP failure for a
particular VLAN pool.
NAT VLAN capacity restored detected by NAT gateway AP due to (at least) one
out of the three (3) consecutive NAT gateway AP IP were down is now up
apNATVlanCapacityRestored
345
Informational
"natGatewayIP"="192.168.10.2", "apMac"="xx:xx:xx:xx:xx:xx"
NAT VLAN capacity restored detected by DHCP NAT AP [{apMac}] one of the
NAT gateway IPs [{natGatewayIP}] is now up, out of three (3) consecutive NAT
Ruckus SmartCell Gateway 200 Virtual SmartZone High Scale and SmartZone 300 Alarm and Event Reference Guide
Part Number: 800-71565-001 Rev A
