Events Types
Gn/S2a Interface Events

GGSN not reachable

TABLE 502 GGSN not reachable event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description

Echo response not received

TABLE 503 Echo response not received event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description

GGSN not resolved

TABLE 504 GGSN not resolved event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description
260
GGSN not reachable
ggsnNotReachable
1211
Major
"mvnoId"="12","ctrlBladeMac"="aa:bb:cc:dd:ee:ff",
"srcProcess"="sm","realm"="NA", "gtpcIp"="5.5.5.5", "ggsnIp"="10.10.10.10",
"SCGMgmtIp"="2.2.2.2"
GGSN [{ggsnIp}] connected to {produce.short.name} (GTPC-IP [{gtpcIp}]) is not
reachable
This event occurs when echo request is timed out.
Echo response not received
echoRspNotRcvd
1212
Informational
"mvnoId"="12", "ctrlBladeMac"="aa:bb:cc:dd:ee:ff", "srcProcess"="sm"
"realm"="NA" "gtpcIp"="5.5.5.5", "ggsnIp"="10.10.10.10",
"SCGMgmtIp"="2.2.2.2"
GGSN [{ggsnIp}] did not respond to Echo Request from {produce.short.name}
(GTPC-IP [{gtpcIp}]) is not reachable
This event occurs when GPRS protocol control plane does not receive an
acknowledgment for the single echo request.
GGSN not resolved
ggsnNotResolved
1215
Major
"mvnoId"="12", "wlanId"="1","zoneId"="10" "ctrlBladeMac"="aa:bb:cc:dd:ee:ff"
"srcProcess"="aut" "realm"="wlan.3gppnetwork.org" "gtpcIp"="5.5.5.5"
"apn"="ruckuswireless.com" "SCGMgmtIp"="2.2.2.2"
"ueMacAddr"="aa:bb:cc:gg:hh:ii" "ueImsi"="12345" "ueMsisdn"="98787"
Failed to resolve GGSN from APN [{apn}] for UE with IMSI [{ueImsi}] and MSISDN
[{ueMsisdn}]
This even occurs when access point name is unable to resolve to gateway GPRS
support node.
